Foundation November 2022 Unit 2 Q10
10. Mark is making an 8-sided spinner.
All of the sections on his spinner are identical.
Mark is going to label each of the sections with one of three colours: blue (B), yellow (Y) or red (R).
Label the spinner below so that when the spinner is spun:
- landing on red and landing on blue are equally likely
AND - it is likely that the spinner lands on yellow. [2]
| Scheme | Marks | Comments |
|---|---|---|
| 6 yellows, 1 blue, 1 red | B2 | B1 for a fully completed spinner satisfying one of the following conditions:
|
