Foundation June 2018 Paper 1 Q9

OCRFoundationCurrent spec3 marksTransformations of Shapes

9 Two shapes are drawn on the grid below.

Grid, x from 0 to 11 and y from 0 to 9. Shape P has vertices (3, 1), (5, 1), (5, 4) and (3, 2). Shape Q has vertices (6, 2), (10, 2), (10, 8) and (6, 4)

Describe fully the single transformation which maps shape P onto shape Q. [3]
