4MA0 Foundation June 2015 Paper 1R Q17
17
(a) Describe fully the single transformation which maps shape P onto shape Q. (2)
(b) Reflect the shape Q in the line \(y = x\)
Label the new shape R. (2)
Label the new shape R. (2)
| Scheme | Marks |
|---|---|
| Reflection (in the line) \(x = 2\) | B1 B1 |
| (2) |
Notes
B1
B1: B1 for reflection, reflect, reflected
B1 for \(x = 2\)
NB If more than one transformation then no marks can be awarded
| Scheme | Marks |
|---|---|
| Vertices at (1, –1) (4, –1) (4, –3) (3, –3) | B2 |
| (2) | |
| Total 4 marks |
Notes
B2: Shape in correct position
If not B2 then B1 for correct orientation of R but wrong position or 3 out of 4 vertices correct
(The printed mark scheme also has a part (c), an enlargement worth 2 marks, and a total of 6 marks for this question. Part (c) is not on this paper, so it is left out here.)
